This page contains plans of Denver, South Park and Pacific
Railroad locomotives that have been collected over many years from various publications.
They are shown
in reduced size to protect the original copyright, which remains with
the artist, author, or publisher.
Most plans show the equipment in its "as built" state; some show
them at a specific date. Numerous updates and modifications,
some unique to specific pieces of rolling stock, occurrred over
the years.
Photos, folio drawings, history, and models of DSP&P
rolling stock appear on other pages of this website
-- see
Site Navigation.
DSP&P Mason Bogie LocomotiveS
Engraving of DSP&P
2-6-6T Mason Bogie #15 "Breckenridge", originally
published in "Railway Gazette" in 1879, reprinted in "Recent
Locomotives" by Mathias Forney in 1886, and again in "Early American
Locomotives" by John White Jr in 1972. Drawn from the builder's photo
shown below.
Click on
image to capture larger image (0.75
Mb)
Builder's Photo,
taken in 1879, of DSP&P
2-6-6T Mason Bogie #15 "Breckenridge". The lettering was probably
gold with red drop-shadow. The boiler was russia iron, probably
light grey or blue, cab and tender box probably dark green or brown,
brightwork polished brass. Photos could not be reproduced in
magazines or newspapers until after 1890 when the duotone process
was invented, so engravers were assigned to redraw photos, as shon above.
DSP&P 2-6-6T Mason Bogies --
General Layout
DSP&P 2-6-6T Mason Bogie --
General Laayout
DSP&P 2-8-6T Mason Bogie --
General Laayout
DSP&P 2-6-6T Mason Bogie #14
"Twin Lakes"
DSP&P
2-6-6T Mason Bogie #3 "Oro City"
DSP&P
2-6-6T Mason Bogie #6 "Tenmile"
DSP&P
2-6-6T Mason Bogie #15 "Breckenridge"
DSP&P 2-6-6T Mason Bogie #6 "Tenmile"
DSP&P 2-6-6T Mason Bogie #8 "Lake City"
shown after 1885 as DSP&P #44
DSP&P 2-6-6T Mason Bogie Variations 1878 - 1883
DSP&P Mason Bogie #3 and #4, "As Delivered" 1878, short tender,
wood cab, arched windows, diamond stack
DSP&P Mason Bogie #3, #4, and #6, 1879, short tender, wood cab,
arched windows, Nesmith stack
DSP&P Mason Bogie #3, #4, and #6, 1883 - 1885, short tender,
metal cab, rectangular windows, Congdon stack, air tank on rear
tender deck
DSP&P Mason Bogie #8, 1883 - 1885, short tender, metal cab,
rectangular windows, Congdon stack, air tank on
DSP&P Mason Bogie #7, #9 - #13 1883 - 1885, long tender, metal cab,
rectangular windows, Congdon stack, air tank on rear of tender
deck,
large headlight
DSP&P 2-8-6T Mason Bogie #28 "Denver"
DSP&P
Mogul Locomotives
DSP&P
2-6-0 Brooks Mogul #30 "Morrison"
DSP&P
2-6-0 Brooks Mogul #33 (#160 after 1884) "Webster"
DSP&P
2-6-0 Brooks Mogul #35 "Dillon"
DSP&P
Consolidation Locomotives
